BVS-F2A 10.1 Inch Android 12 Rugged Tablet PC, MediaTek MT8788 5G 8GB+128GB, IP67 Waterproof Compact Field Data Terminal, Glove & Wet Hand Touch

Overview &Key Features

【Model】BVS-101-F2A

【Item】

BVS-F2A is a compact 10.1-inch IP67-rated rugged Android tablet built for cost-effective field data collection in logistics, retail chain management and light industrial environments. Its slim 284×189×25mm reinforced chassis and 1150g lightweight design make it easy to carry and operate with one hand for a full shift. Rated IP67, it resists dust, water immersion and drops up to 0.8 meters, ensuring dependable service in tough daily working conditions.Powered by the MediaTek MT8788 octa-core 5G processor with 8GB RAM and 128GB storage, it runs Android 12 smoothly for custom field apps, mobile order management and asset scanning. The 10-point capacitive touch supports glove and wet-hand operation, and is customizable with anti-glare, anti-reflection, shockproof or EMR special screens to match specific deployment environments. The 550cd/m² high-brightness IPS display (optional 700/1000cd/m²) stays readable outdoors. An 8000mAh removable gel-polymer battery supports long working hours, while the rear 8MP autofocus camera captures on-site documentation. Flexible options include NFC, GPS/GNSS, fingerprint, ID card reader and barcode scanning modules for tailored project needs.

【Notice】

For custom specifications or wholesale inquiries, please contact our sales team.

Payment Terms:

  • Sample orders: 100% upfront

  • Bulk orders: 30% deposit, 70% balance before shipment

Lead Times:

  • Samples: 7 working days after payment confirmation

  • Bulk orders: shipping schedule to be negotiated

Shipping:Freight costs are borne by the buyer. Contact us for a quote.

Warranty:2-year standard warranty included.

【Parameter List】

Basic Parameters Product Model 101-F2A
Description Android 10.1" Rugged Tablet
Weight Net 1150g
Keys Power, Volume +/-, Custom keys, Shortcut keys
Screen Size 10.1" 16:10 IPS
Resolution 1200(H) x 1920(V)
Brightness Standard 550cd/㎡, Optional 700/1000cd/㎡
Touch Panel Capacitive, 10-point (G+F+F), supports glove & wet hand mode,
customizable EMR/Anti-glare/Anti-reflection/Shockproof/Special screen
Battery 7.6V/8000mAh (removable gel polymer Li-battery)
Camera Front 5.0MP, Rear 8.0MP with autofocus
Speaker & Mic Built-in 8Ω/2W*2, waterproof speaker x1
Hardware Configuration CPU 5G MT8788, 2x2.2GHz Cortex-A76, 6x2.0GHz Cortex-A55
GPU Mali-G57 MC2
RAM 8GB
SSD 128GB
Gyroscope Built-in
Accelerometer Built-in
Compass Built-in
E-Compass Built-in
Operating System Android 12.0
Network Connectivity WIFI WIFI5, supports 4G global/5G module
Bluetooth BT4.2 (BLE) Class1, Range 10m
4G/5G Optional
GNSS Optional
GPS Optional
RFID Optional
NFC Optional
Optional Modules Barcode/QR Code Optional
High-Precision Positioning Optional
Fingerprint Optional
ID Card Reader Optional
UHF RFID Optional
I/O Interfaces USB Ports USB 3.0 ×1
Headphone Jack 3.5mm standard headphone ×1
TF Card Supported, Max 256GB
SIM Card Single SIM
HDMI HDMI 1.4 Mini ×1
DC Port DC 3.5×1.35mm (optional aviation connector)
POGO PIN Rear 2-pin, Bottom 11-pin
DB9 Port ×1 Default pin I/O (RS232/485 DB9 optional)
RJ45 Port ×1
Type-C Default data only
Power & Rugged Features Power Adapter AC100–240V input, DC19V/3.42A output
Protection Rating IP67
Drop Resistance 0.8m
Operating Temp. -15°C ~ 50°C
Storage Temp. -20°C ~ 60°C
Humidity 95% non-condensing
ESD Protection ±6kV contact discharge, ±12kV air discharge
