BVS‑ZR‑270 27 Inch Exhibition Hall Interactive Demo Android Touch Screen, RK3566 2+32GB, Debian Linux Museum Information Kiosk, ABS Plastic Wall‑Mount Commercial All‑in‑One PC
Overview &Key Features
【Model】BVS-ZR270
【Item】
BVS-ZR 14–32" All-in-One Android Panel PC – RK3566 for Industrial Monitoring
BVS‑ZR‑270 is a large‑size interactive exhibition terminal for enterprise showrooms and cultural exhibition halls. The lightweight ABS plastic casing reduces wall‑mount load while presenting a clean exhibition visual effect in black or white. Powered by RK3566 2GB+32GB hardware, this touch machine plays Android multimedia exhibition content including product videos and picture albums. Debian Linux supports museum and enterprise exhibition teams to build customized story‑telling guide systems. Visitors can touch the screen to browse exhibit background information, brand development history and technical introduction, acting as a digital docent for exhibition scenarios.
【Notice】
For custom specifications or wholesale inquiries, please contact our sales team.
Payment Terms:
-
Sample orders: 100% upfront
-
Bulk orders: 30% deposit, 70% balance before shipment
Lead Times:
-
Samples: 7 working days after payment confirmation
-
Bulk orders: shipping schedule to be negotiated
Shipping:Freight costs are borne by the buyer. Contact us for a quote.
Warranty: 2-year standard warranty included.
【Parameter List】
| Standard | optional | ||||||||||
| System | CPU | Rockchip RK3566 Quad-core Cortex-A55 | / | ||||||||
| Frequency | 2.0 GHz | / | |||||||||
| GPU | Quad-core GPU | / | |||||||||
| NPU | 1TOPS NPU | / | |||||||||
| DDR | 2GB | 4GB | |||||||||
| EMMC | 32GB | 16GB | |||||||||
| Operating system | Android 11 | / | |||||||||
| Display | Screen | 27.0 inch Industrial LCD Screen | / | ||||||||
| Resolution | 1920(RGB)×1080 [FHD] | / | |||||||||
| Viewing angle | 89/89/89/89 (Typ.) (CR≥10) | / | |||||||||
| Contrast ratio | 3000:1 (Typ.) (Transmissive) | / | |||||||||
| Brightness | 300 cd/m2 (Typ.) | 500 cd/m2 | |||||||||
| Screen scale | 16:9 | / | |||||||||
| Network | Wi-Fi | 2.4G Wi-Fi, 802.11b/g/n | 5G Wi-Fi | ||||||||
| Ethernet | 1 x Gigabit Ethernet (RJ45) | / | |||||||||
| BT | Bluetooth | / | |||||||||
| 4G LTE | / | / | |||||||||
| Interfaces | USB | USB Host * 3 | / | ||||||||
| COM | / | TTL / RS232 / RS485 * 2 (support external NFC, Printer, Scanner, etc.) | |||||||||
| HD | / | / | |||||||||
| TF card slot | Max support 32GB TF card | / | |||||||||
| LAN | 1 | / | |||||||||
| SIM-4G | 1 | / | |||||||||
| DC-IN | 1 | / | |||||||||
| Multi-Media | Video | H.264, VP8, MAV, WMV, AVS, H.263, MPEG4 1080P multi-video decoding, YouTube, etc. | / | ||||||||
| Audio | MP3, WMA, WAV, APE, FLAC, AAC, OGG, M4A, 3GPP | / | |||||||||
| Picture | JPG, BMP, PNG formats browsing, rotation, slide show, zoom | / | |||||||||
| Accessories | Adapter | DC 12V / 5A | / | ||||||||
| Temperature | Working temperature | -20°C ~ 60°C | / | ||||||||
| Storage temperature | / | / | |||||||||
| Mounting | VESA Mount | / | Customizable | ||||||||
| Panel Mount | / | Customizable | |||||||||
| Stand Mount | / | Customizable | |||||||||
| Packaging | Net weight | 5.66kg | / | ||||||||
| Gross weight | 7.16kg | / | |||||||||
| Product dimensions | 662*400*19mm（L*W*H） | / | |||||||||
| Single Unit Package Dimension | 700*198*115mm（L*W*H） | / | |||||||||
| Carton Dimension | / | / | |||||||||
| Other functions | Camera | 2MP | (1.3MP 720P, 2MP 1080P, 5MP) | ||||||||
| NFC | / | (ISO/IEC14443A) | |||||||||
| RFID | / | / | |||||||||
| POE | / | Support POE power supply | |||||||||
| OEM | Appearance, Interface, CPU, Logo, etc. | ||||||||||
