BVS‑ZR‑185 18.5 Inch Hotel Lobby Service Android Touch Display, RK3566 2GB+32GB, Debian Linux Guest Information Inquiry Kiosk, ABS Plastic Wall‑Mount Digital Signage
Overview &Key Features
【Model】BVS-ZR185
【Item】
BVS-ZR 14–32" All-in-One Android Panel PC – RK3566 for Industrial Monitoring
BVS‑ZR‑185 is an 18.5‑inch hotel‑specialized interactive service terminal with lightweight ABS plastic construction, available in elegant black and white finishes to match hotel lobby style. Powered by RK3566 and 2GB+32GB memory, it runs Android hotel service systems for guests to check surrounding attractions, restaurant recommendations and room service applications. Debian Linux supports hotel system docking for advanced customized functions. Installed on the lobby wall, this touch screen acts as a 24‑hour self‑service concierge, providing tourist guides, facility introduction and activity notifications for hotel guests, reducing reception staff workload for boutique hotels and resort apartments.
【Notice】
For custom specifications or wholesale inquiries, please contact our sales team.
Payment Terms:
-
Sample orders: 100% upfront
-
Bulk orders: 30% deposit, 70% balance before shipment
Lead Times:
-
Samples: 7 working days after payment confirmation
-
Bulk orders: shipping schedule to be negotiated
Shipping:Freight costs are borne by the buyer. Contact us for a quote.
Warranty: 2-year standard warranty included.
【Parameter List】
| Standard | optional | ||||||||||
| System | CPU | Rockchip RK3566 Quad-core Cortex-A55 | / | ||||||||
| Frequency | 2.0 GHz | / | |||||||||
| GPU | Quad-core GPU | / | |||||||||
| NPU | 1TOPS NPU | / | |||||||||
| DDR | 2GB | 4GB | |||||||||
| EMMC | 32GB | 16GB | |||||||||
| Operating system | Android 11 | / | |||||||||
| Display | Screen | 13.3 inch Industrial LCD Screen | / | ||||||||
| Resolution | 1920(RGB)×1080 , WXGA | / | |||||||||
| Viewing angle | 89/89/89/89 (Typ.) (CR≥10) | / | |||||||||
| Contrast ratio | 700:1 (Typ.) (Transmissive) | / | |||||||||
| Brightness | 300 cd/m2 (Typ.) | / | |||||||||
| Screen scale | 16:9 | / | |||||||||
| Network | Wi-Fi | 2.4G Wi-Fi, 802.11b/g/n | 5G Wi-Fi | ||||||||
| Ethernet | 1 x Gigabit Ethernet (RJ45) | / | |||||||||
| BT | Bluetooth | / | |||||||||
| 4G LTE | / | / | |||||||||
| Interfaces | USB | USB Host * 3 | / | ||||||||
| COM | / | TTL / RS232 / RS485 * 2 (support external NFC, Printer, Scanner, etc.) | |||||||||
| HD | / | / | |||||||||
| TF card slot | Max support 32GB TF card | / | |||||||||
| LAN | 1 | / | |||||||||
| SIM-4G | 1 | / | |||||||||
| DC-IN | 1 | / | |||||||||
| Multi-Media | Video | H.264, VP8, MAV, WMV, AVS, H.263, MPEG4 1080P multi-video decoding, YouTube, etc. | / | ||||||||
| Audio | MP3, WMA, WAV, APE, FLAC, AAC, OGG, M4A, 3GPP | / | |||||||||
| Picture | JPG, BMP, PNG formats browsing, rotation, slide show, zoom | / | |||||||||
| Accessories | Adapter | DC 12V / 5A | / | ||||||||
| Temperature | Working temperature | -20°C ~ 60°C | / | ||||||||
| Storage temperature | / | / | |||||||||
| Mounting | VESA Mount | / | Customizable | ||||||||
| Panel Mount | / | Customizable | |||||||||
| Stand Mount | / | Customizable | |||||||||
| Packaging | Net weight | 2.46kg | / | ||||||||
| Gross weight | 3.57kg | / | |||||||||
| Product dimensions | 282*462*37mm （L*W*H） | / | |||||||||
| Single Unit Package Dimension | 525*115*395mm （L*W*H） | / | |||||||||
| Carton Dimension | 540*500*420mm （L*W*H）(Ctn Qty:5 pcs) | / | |||||||||
| Other functions | Camera | 2MP | (1.3MP 720P, 2MP 1080P, 5MP) | ||||||||
| NFC | / | (ISO/IEC14443A) | |||||||||
| RFID | / | / | |||||||||
| POE | / | Support POE power supply | |||||||||
| OEM | Appearance, Interface, CPU, Logo, etc. | ||||||||||
