【Model】BVS-YL101 V3.0

【Item】

BVS-YL101 V3.0 is a 10.1 inch Android touch panel with a white ABS housing, designed for medical and healthcare environments such as hospitals, clinics, rehabilitation centers and laboratories. It integrates LAN, SIM, OTG, 12V DC power input and two GPIO interfaces, providing a flexible platform for patient bedside terminals, nurse station dashboards, check-in kiosks and customer feedback terminals.

【Notice】

Please contact us if you need other specifications.
Payment terms: Samples 100% payment in advance, bulk order 30% deposit, 70% payment before shipment.Sample order accepted.
Sample delivery time is 7 working days after payment received, for bulk order, shipping time is negotiated.
The shipping fees should covered by buyers, please contact us for details.
Provide service: For batch orders to print logo and design box etc.
Warranty: One year.

【Parameter List】

Category	Item	BVS-YL101 V3.0 Specification
Specification	CPU	RK3566
	RAM	2GB
	Storage	32GB
	Operating system	Android 11
Display	Size	10.1 inch capacitive touch
	Resolution	1280 × 800
	Brightness	250–300 cd/m² (typical, if applicable)
Interfaces	Network	1 × LAN (RJ45)
	USB	1 × OTG
	Cellular	1 × SIM card slot (for 4G/LTE module if available)
	GPIO	2 × GPIO interfaces
	Power input	1 × 12V DC jack
Environment	Operating temperature	0–50 ℃
Environment	Storage temperature	−20–60 ℃
Certification	Compliance	CE, FCC, RoHS,ISO9001,ISO14001,etc.
Package contents	Standard accessories	Device, wall-mount kit, power adapter, screws, manual
Customization	OEM/ODM options	Housing color, logo, memory, interfaces, firmware
